Optic Fiber Insertion Return Loss Tester good performance Insertion Loss tester JW3308 - copy

Power Supply: AC100~240V 50/60Hz
Brand:TriBrer
Mode:HCF
isplay Resolution: 0.01& 0.001 dB
Product description: Optic Fiber Insertion Return Loss Tester good performance Insertion Loss tester JW3308
INQUIRY

Insertion Return Loss Tester, Insertion Loss and Return Loss Test Station

Features:

TriBrer Fiber Optic Insertion Return Loss Tester GRL200 Insertion Loss and Return Loss Test Station

Specifications

Model	GRL200
Return Loss Module
Calibration Wavelength	1310nm&1550nm (option:1490nm)
Test Range	0~75 dB
Accuracy	0~50dB: 0.5dB; 50~75dB: 0.8dB
Display Resolution	0.01& 0.001 dB
Connector	FC/APC
Insertion Loss & Power Meter Mode
Calibration Wavelength	850nm / 1300nm / 1310nm / 1490nm / 1550nm / 1625nm
Test Range	+4 ~ -80 dBm
Accuracy	±0.2dB
Display Resolution	0.001 & 0.01 dBm
Connector	FC / SC / LC / 2.5UPP / 1.25UPP
Laser Source Mode
Wavelength	1310 & 1550 & 850nm (option:1490nm)
Output Power	-2 dBm ± 0.5 dB (850nm: -10dBm ± 0.5 dB)
Connector	FC/APC (850nm: FC/PC)
VFL	650nm, 1mW
Others
Display	3.5 inch color LCD
Easy Guider	Yes
Power Supply	AC100~240V 50/60Hz
