General Description:
The FHR3A02 is a high performance optical fiber troubleshooter for locating fiber break and imperfections. It detects the location of break point&attenuation points in the optical fiber and displays the result on the LCD. This portable, easy to use fiber ranger is an ideal instrument for fiber cable construction and maintenance.
Features:
-Low Dead Zone of only 10 meters;
-Back-light LCD display;
-Rechargeable batteries support up to 5000 times measurement;
-Data transmission&.storage through mini USB;
-Build-in Visual Fault Locator
Specifications:
|
Item / Model No. |
FHR3A02 |
|
|
Fiber Type |
9/125 μm Single Mode |
|
|
Wavelength |
1550 ± 20nm |
|
|
Emitter Type |
LD |
|
|
Connector Type |
FC/PC (interchangeable SC,ST) |
|
|
Pulse Width |
10ns/20ns/40ns/80ns/160ns/320ns/640ns/1280ns/ 2560ns/5120ns/10240ns/20480ns |
|
|
Max. Output Power |
90 mW |
|
|
Max. Measurement Range |
100 Km(Reflection event, >1dB) |
|
|
Distance Accuracy |
Reflection event |
± (2 + 0.1% x Distance) |
|
Non-Reflection event |
± (100 + 0.5% x Distance) |
|
|
Data Storage |
260 measurements |
|
|
Dead Zone |
10 m (Reflection event ) |
|
|
Power Supply |
AC/DC adaptor &. Rechargeable Batteries* 4 |
|
|
Battery Life |
5,000 times measurement |
|
|
Operating Temp |
-10 ~ +50oC |
|
|
Storage Temp |
-20 ~ +60oC |
|
|
Humidity |
0 ~ 85% (non-condensing) |
|
|
Communication Port |
Mini USB |
|
|
Weight |
400 g |
|
|
Dimension |
190*105*55 mm |
|
|
Max Event No. |
13 Refective event+13 Non-refective event |
|
|
VLF |
Wavelength |
650±10nm |
|
Output Power |
5mW ( +/- 1mW changeable) |
|
|
Modulated Frequency |
2Hz |
Note: Specifications subject to change without notice.
