OTDR

Grandway Fiber Optical Cable Fault Locator OTDR Max EXFO OTDR

Model Number: FHO5000-MD21
Wavelength: 850/1300/1310/1550nm
Dynamic range: 19/21/35/33dB
Application: SM and MM fiber testing
产品描述：Grandway Fiber Optical Cable Fault Locator OTDR Max EXFO OTDR
在线订购

Packaging & Delivery

Packaging Details	in carton
Delivery Time	depend on the quantity

Grandway F2H Free Remote Demo 1310/1550nm, 26/24 dB, Built-in VFL, Touch Screen, Long Distance 130km, FC/SC OTDR

Product Description

Fiber Optic OTDR
SM OTDR / MM OTDR / PON OTDR / SM & MM OTDR

FHO5000 series OTDR is a highly integrated platform that features with four module slots, with a large 7-inch color screen (with a touchscreen option), a high-capacity Lithium-Ion battery, an optional microscope (through universal serial bus [USB] port), and built-in optical test functions, such as PON test module, visual fault locator (VFL), optional power meter, and laser source, making it qualified in the installation, turn-up, and maintenance of FTTx/Access optical networks.

FHO5000 series OTDR is a highly integrated platform that features with four module slots, with a large 7-inch color screen (with a touchscreen option), a high-capacity Lithium-Ion battery, an optional microscope (through universal serial bus [USB] port), and built-in optical test functions, such as PON test module, visual fault locator (VFL), optional power meter, and laser source, making it qualified in the installation, turn-up, and maintenance of FTTx/Access optical networks.

The OTDR 1) With Touch Screen 2) With Optical Laser Source 3) With Optical Power Meter 4) With Visual Fault Locator 5) With FC/SC Connectors 6) With Calibrate certificate & Test Report	Extra Service 1) Free recalibrated. (generally, every 3 years) 2) Free built-in Specific language 3) Free software update 4) Free OTDR questions answer 5) Free Join in our OTDR training class 6) Free 365 days gurantee

The OTDR
1) With Touch Screen
2) With Optical Laser Source
3) With Optical Power Meter
4) With Visual Fault Locator
5) With FC/SC Connectors
6) With Calibrate certificate & Test Report

Extra Service
1) Free recalibrated. (generally, every 3 years)
2) Free built-in Specific language
3) Free software update
4) Free OTDR questions answer
5) Free Join in our OTDR training class
6) Free 365 days gurantee

OTDR Model#	Wavelength (nm)	Dynamic Range (dB)	Event/Attenuation Dead Zone(m)
FHO5000-D26	1310/1550	26/24	0.8/4
FHO5000-D32	1310/1550	32/30	0.8/4
FHO5000-D35 [hot~]	1310/1550	35/33	0.8/4
FHO5000-D40	1310/1550	40/38	1/4
FHO5000-D43	1310/1550	43/41	1/5
FHO5000-T40F	1310/1550/1625	40/38/38	1/4
FHO5000-T43F	1310/1550/1625	43/41/41	1/5
FHO5000-M21	850/1300	19/21	0.8/4
FHO5000-MD21	850/1300/1310/1550	19/21/35/33	0.8/4/1/4
FHO5000-MD22	850/1300/1310/1550	19/21/40/38	0.8/4/1/4
